MSI B760M Bomber mATX Motherboard

Information:

MSI B760M Bomber mATX Motherboard | Micro-ATX | Supports Intel® 12th / 13th / 14th Gen Core™, Pentium® Gold & Celeron® Processors (LGA 1700) | DDR5 Memory Boost 6400+MHz (OC) | PCIe 4.0 | Dual M.2 with Shield Frozr | SATA 6Gb/s | USB 3.2 Gen1 | HDMI 2.1 & DisplayPort 1.4 | 2.5G LAN | Audio Boost | 1-Year Warranty

Description:

Description:

▸ SKU: 911-7D90-041
▸ Chipset: Intel® B760
▸ CPU Support: Intel® 12th / 13th / 14th Gen Core™, Pentium® Gold, and Celeron® Processors (LGA 1700 Socket)
▸ Memory: 2× DDR5 DIMMs | Up to 128GB | Dual Channel | 4800–6400+MHz (OC) | Intel® XMP 3.0 | Non-ECC, unbuffered
▸ Audio: Realtek® ALC897 | 7.1-Channel High Definition Audio | Audio Boost
▸ Storage: 2× M.2 (PCIe 4.0 x4 / SATA) | 4× SATA 6Gb/s | Supports RAID 0/1/5/10
▸ LAN: Realtek® RTL8125B 2.5Gbps Ethernet
▸ Wireless: –
▸ Onboard Graphics: 1× HDMI™ 2.1 (4K@60Hz, HDR) | 1× DisplayPort 1.4 (4K@60Hz) | 1× VGA D-Sub (2048×1536@50Hz) — depends on CPU with iGPU
▸ Expansion Slots: 1× PCIe 4.0 x16 | 1× PCIe 4.0 x1
▸ USB Ports: Rear — 2× USB 2.0, 4× USB 3.2 Gen1 Type-A (5Gbps) | Front — 4× USB 2.0, 2× USB 3.2 Gen1 Type-A
▸ Internal I/O: ATX_PWR, CPU_PWR, CPU Fan, 2× System Fan, Front Panel, Chassis Intrusion, Front Audio, COM, 2× JARGB_V2, 1× JRGB, TPM 2.0 header, USB 2.0 header, USB 3.2 Gen1
▸ LED Feature: 4× EZ Debug LED
▸ Back Panel Ports: HDMI™, DisplayPort, VGA, PS/2 Combo Port, USB 2.0, USB 3.2 Gen1, 2.5G LAN, Audio Jacks
▸ Operating System: Windows® 11 / 10 (64-bit)
▸ PCB Form Factor: mATX (220mm × 243.84mm / 8.66″ × 9.60″)
