MSI B760M Gaming Plus WiFi DDR4 mATX Motherboard

Information:

MSI B760M Gaming Plus WiFi DDR4 mATX Motherboard – Intel 14th / 13th / 12th Gen Support

Description:

▸ SKU: 911-7D99-065
▸ Chipset: Intel® B760
▸ Socket: LGA 1700
▸ CPU Support: Intel® Core™ 14th / 13th / 12th Gen, Pentium® Gold, Celeron®
▸ Form Factor: Micro-ATX (243.84 × 243.84 mm)

▸ Memory:
  • 4× DDR4 DIMM, up to 128GB
  • Dual-Channel, Non-ECC, Unbuffered
  • Intel® XMP 3.0 Support
▸ Memory Speeds (OC):
  5333 / 5200 / 5066 / 5000 / 4800 / 4600 / 4400 / 4266 / 4200 / 4000 / 3800 / 3733 / 3600 / 3466 / 3400 / 3333 / 3200 (JEDEC) / 2933 / 2666 / 2400 / 2133 MHz

▸ Graphics Outputs:
  • 2× HDMI™ 2.1 (4K@60Hz)
  • 2× DisplayPort 1.4 (4K@60Hz)

▸ Expansion Slots:
  • 1× PCIe 4.0 x16 (Steel Armor)
  • 1× PCIe 3.0 x16 (x4)
  • 1× PCIe 3.0 x1

▸ Storage:
  • 2× M.2 (PCIe 4.0 x4 / SATA)
  • 4× SATA 6Gb/s
▸ RAID Support: RAID 0 / 1 / 5 / 10 (SATA)

▸ Networking:
  • Realtek® RTL8125BG 2.5G LAN
  • Intel® Wi-Fi 6E + Bluetooth® 5.3

▸ Audio: Realtek® ALC897, 7.1-Channel HD Audio (Audio Boost)

▸ USB Ports (Rear):
  • 2× USB 10Gbps Type-A
  • 2× USB 5Gbps Type-A
  • 2× USB 2.0

▸ USB Ports (Front):
  • 4× USB 5Gbps Type-A
  • 1× USB 5Gbps Type-C
  • 4× USB 2.0

▸ Internal Headers:
  ATX_PWR, 2× CPU_PWR, CPU Fan, Pump Fan, 2× System Fan, JFP, JCI, JAUD, JCOM,
  2× JARGB_V2, 1× JRGB, TPM 2.0, Front USB

▸ Cooling Support: AIO & Custom Water Cooling Ready (3A Pump Header)
▸ Thermal Design: Extended Heatsink, M.2 Shield Frozr, 7W/mK Thermal Pads
▸ RGB Support: Mystic Light RGB & ARGB
▸ Debug: 4× EZ Debug LEDs
▸ Protection: OCP, TVS, Solid Pin Connectors, Stainless Steel I/O Shield
▸ Operating System: Windows® 11 / 10 (64-bit)

▸ Box Contents:
  B760M Gaming Plus WiFi DDR4 Motherboard, Wi-Fi Antennas, I/O Shield, SATA Cables, Manuals, Driver Kit
