MSI B760M Gaming Plus WiFi DDR5 Motherboard

Information:

MSI B760M Gaming Plus WiFi Motherboard – Intel 14th / 13th / 12th Gen Support (DDR5)

Description:

▸ SKU: 911-7D99-060
▸ Chipset: Intel® B760
▸ Socket: LGA 1700
▸ CPU Support: Intel® Core™ 14th / 13th / 12th Gen, Pentium® Gold, Celeron®
▸ Form Factor: Micro-ATX (243.84 × 243.84 mm)
▸ Memory:
  • 4× DDR5 DIMM, up to 192GB
  • Dual-Channel, Non-ECC, Unbuffered
  • Intel® XMP 3.0 Support
▸ Memory Speeds (OC):
  6800+ / 6600 / 6400 / 6200 / 6000 / 5800 / 5600 / 5400 / 5200 / 5000 / 4800 MHz
▸ Graphics Outputs:
  • 2× HDMI™ 2.1 (4K@60Hz)
  • 2× DisplayPort 1.4 (4K@60Hz)
▸ Expansion Slots:
  • 1× PCIe 4.0 x16 (Steel Armor)
  • 1× PCIe 4.0 x4 (from Chipset)
  • 1× PCIe 3.0 x1
▸ Storage:
  • 2× M.2 (PCIe 4.0 x4 / SATA)
  • 4× SATA 6Gb/s
▸ RAID Support: RAID 0 / 1 / 5 / 10 (SATA)
▸ Networking:
  • Realtek® RTL8125BG 2.5G LAN
  • Intel® Wi-Fi 6E + Bluetooth® 5.3
▸ Audio: Realtek® ALC897, 7.1-Channel HD Audio (Audio Boost)
▸ USB Ports (Rear):
  • 2× USB 10Gbps (Gen 2) Type-A
  • 2× USB 5Gbps (Gen 1) Type-A
  • 2× USB 2.0
▸ USB Ports (Front):
  • 4× USB 5Gbps Type-A
  • 1× USB 5Gbps Type-C
  • 4× USB 2.0
▸ Internal Headers:
  ATX_PWR, 2× CPU_PWR, CPU Fan, Pump Fan, 2× System Fan, 2× JFP, JCI, JAUD, JCOM,
  2× JARGB_V2, 1× JRGB, TPM 2.0
▸ Cooling & Thermal: Extended Heatsink, 7W/mK Pads, M.2 Shield Frozr, 3A Pump Header
▸ Debug: 4× EZ Debug LEDs
▸ Operating System: Windows® 11 / 10 (64-bit)
▸ Warranty: 1 Year Limited Warranty
▸ Box Contents:
  B760M Gaming Plus WiFi Motherboard, Wi-Fi Antennas, SATA Cables, IO Shield, Quick Install Guide
